ZQY60D Fully Automatic Extrusion Blow Molding Machine（Double Station）
Our double-station Extrusion Blow Moulding Machine extrudes plastic into hollow parisons and distributes them to two independent molding stations for alternating operation, realizing non-stop continuous production. The equipment supports processing PE, PP, PVC and other materials, is equipped with precise PLC control system, and can realize multi-layer co-extrusion molding of special components, greatly improving production efficiency while ensuring product consistency.
| Max.Product Volume | （L） | 2 |
| Theoretical Output | (PC/h) | 800×2 |
| Screw Diameter | (mm) | 60 |
| Screw L/D ratio | (L/D) | 24-30 |
| Screw drive power | (KW) | 15-18.5 |
| Screw heating capacity | (KW) | 10.8-12 |
| Output of HDPE | (kg/h) | 60-75 |
| Oil pump drive power | (KW) | 5.5 |
| Clamping force | (KN) | 40 |
| Platen size | (W×H)mm | 338×410 |
| Platen Opening Stroke | (mm) | 138~368 |
| Max.Die diameter | (mm) | 90 |
| Central distance of bi-die | (mm) | 130-150 |
| Max.Die Diameter(Bi-die) | (mm) | 80 |
| Central distance of three-die | (mm) | 80-110 |
| Max.Die Diameter(three-die) | (mm) | 40 |
| Central distance of four-die | (mm) | 60-85 |
| Max.Die Diameter(four-die) | (mm) | 25 |
| Average Energy Consumption | (kw/h) | 16.5 |
| Blowing pressure | (Mpa) | 0.6 |
| Air Consumption | (M³MIN) | 0.4 |
| Cooling water pressure | (Mpa) | 0.3 |
| Water consumption | (L/MIN) | 60 |
| Size of machine | (L×W×H)/m | 3.1×2.15×2.6 |
| Weight of machine | (TON) | 6.5 |
