Zhangjiagang Ziqiang Machinery Co., Ltd. is an injection blow molding machine (IBM) factory in Jiangsu, China. We build one-step IBM machines for small plastic bottles used in pharmaceutical, cosmetic, food and household packaging. This guide explains our machine range, typical applications and the checks that help you compare suppliers before you send an inquiry.
All-Electric, Servo & Hydraulic Injection Blow Molding Machines
We offer three drive options, so you can match the injection blow molding machine to your budget, energy cost and bottle type.• All-electric: Electric motors drive the main movements instead of hydraulic oil. This suits clean packaging such as pharmaceutical and eye drop bottles, and it usually lowers energy use.
• Servo: A servo motor controls the hydraulic system. It saves energy compared with a standard hydraulic setup and keeps movement stable.
• Hydraulic: A proven design with simple maintenance. It is a practical choice when purchase price matters most.
Our IBM machines use a one-step process and PLC control. Tell us your bottle, output target and local power supply, and we will suggest the right drive option.
ZQ40 to ZQ135 IBM Machine Series for Small Plastic Bottles
Our Injection Blow Molding Machine range includes five models: ZQ40, ZQ60, ZQ80, ZQ110 and ZQ135. Several models let you choose a size that fits your bottle volume, cavity number and production plan, so you do not pay for capacity you do not need.Exact specifications depend on the model and the mold. These include clamping force, injection volume, cavity number and bottle size range. The right choice depends on your bottle, so send us a sample or drawing. Our team will recommend a model and confirm the specifications in writing.
Injection Blow Molding Machine for Pharmaceutical Bottles
Pharmaceutical packaging puts quality first. Tablet, capsule, syrup and ointment bottles need accurate neck threads, smooth inner surfaces and consistent weight. An injection blow molding machine suits this work because the injection mold forms the neck, and the finished bottle has no weld seam and no flash to trim.Material and cleanliness matter as much as the machine. Check that your resin, production environment and bottle design meet the rules in your target market. We can discuss machine configuration and mold design with your quality team.
Injection Blow Molding Machine for Cosmetic and Eye Drop Bottles
Cosmetic and eye drop bottles are small, and every detail shows. Buyers usually need tight neck dimensions for droppers and pumps, clear or evenly colored walls, and a clean base. An IBM machine forms these features in one cycle, so the bottles come out finished. Typical products include:• Eye drop and dropper bottles
• Lotion, skin care and personal care bottles
• Sample and travel-size bottles
Multi-cavity molds can raise output for small bottle sizes. Ask us which cavity layout fits your machine model and bottle size.
Blow Molding Machine for Food and Household Bottles
Small bottles for food and daily use are a steady market. Examples include seasoning bottles, supplement bottles and household product bottles. Our applications also cover larger-volume bottles, so you can discuss several bottle types with one supplier.For food contact, choose a food-grade resin and confirm the rules in your import market. We can help you plan the mold and the blow molding machine around the resin you select.
Blow Molding Machine Manufacturer & Supplier in China
Zhangjiagang Ziqiang Machinery Co., Ltd. is based in Zhangjiagang City, Jiangsu Province, China. These are the facts buyers ask about most:• 20+ years of industry experience
• 50+ employees
• 1000+ ㎡ of factory area
• Customers in 30+ countries and regions
• Exhibitor at CHINAPLAS 2026, Shanghai (April 21–24, Booth 8.1B09)
Our range goes beyond injection blow molding. We also supply extrusion blow molding machines, injection stretch blow molding machines, auxiliary machines and molds. This helps buyers who want one blow molding machine manufacturer for several packaging projects.
Blow Molding Machine for Sale: Get a Factory Price Quote
A good quotation starts with good information. Before you request a blow molding machine price, prepare these details:• Bottle sample, drawing or photo
• Bottle volume and neck size
• Resin type, such as HDPE, PP or PET
• Target output per hour
• Preferred drive type: all-electric, servo or hydraulic
• Voltage and frequency
• Destination port
Send these details through our Contact us page. A clear request leads to a faster and more accurate offer.
OEM/ODM Bottle Molds and Turnkey Injection Blow Molding Solutions
The mold affects bottle quality as much as the machine does. We support OEM/ODM bottle molds, so you can develop your own bottle design with our team. Browse our Mold range to see the mold options we supply.We also build turnkey projects, with the machine, mold and supporting equipment from one supplier. Supporting equipment includes auxiliary machines such as a bottle neck trimming machine for PE, PVC, PP, PET and PC bottles, rated at 500–1100 pcs/h. One supplier for the full line reduces matching problems at start-up.
Worldwide Export, Installation and After-Sales Support
We offer worldwide export support and sell to buyers in 30+ countries and regions. For overseas projects, agree on these points in writing before you place an order:• Delivery terms (EXW, FOB or CIF) and shipping port
• Packing method and export documents
• Installation guidance and operator training
• Spare parts list and supply
• Warranty terms and technical support channel
For technical questions, reach our team by email at isabel@ziqiangmachine.com or on WhatsApp at +86 13913614902.
What Is an Injection Blow Molding Machine?
An injection blow molding machine makes hollow plastic bottles in one continuous process. It injects molten plastic into a mold to form a preform with the finished neck, then blows the preform into the final bottle shape. It is mainly used for small, precise bottles.Unlike extrusion blowing, IBM forms the neck by injection. The thread is accurate, and the bottle needs no neck trimming. Most IBM machines are built for small and medium bottle sizes.
How Does an IBM Machine Make Small Plastic Bottles?
The process has four steps:
1. Injection: The machine melts plastic and injects it around a core rod to form a preform.
2. Transfer: The core rod moves the preform to the blowing station.
3. Blowing: Compressed air inflates the preform against the bottle mold.
4. Ejection: The machine releases the finished bottle, and the cycle repeats.
These steps run at the same time on different stations. This keeps cycle times short and results repeatable.
Injection Blow Molding vs Extrusion Blow Molding: Which Is Better for Small Bottles?
Both methods make hollow bottles, but they suit different jobs. Our guide, Types of Blow Molding Machine: 3 Main Types Explained, covers EBM, IBM and ISBM in more detail. This table gives a general comparison:| Feature | Injection Blow Molding (IBM) | Extrusion Blow Molding (EBM) |
| Neck accuracy | High. The neck is injection molded. | Lower. The neck usually needs trimming. |
| Material waste | Very little. No flash. | Flash is trimmed and usually reground. |
| Typical bottle size | Small to medium | Small to very large |
| Handles and complex shapes | Limited | Possible |
| Wall thickness | Consistent and easy to control | Depends on parison control |
| Best for | Pharmaceutical, cosmetic and eye drop bottles | Jerry cans, drums and large bottles |
For small bottles with precise necks, IBM is usually the better fit. For larger bottles, handles or irregular shapes, EBM is often more practical. For PET bottles that need high clarity and strength, ISBM is the usual route. We supply all three machine types.
How to Choose the Right Blow Molding Machine for Your Bottle Size and Output
Bottle size, shape and neck
List the bottle volume, neck finish and wall thickness first. IBM works best for small bottles with precise necks. If your design has a handle, consider EBM instead.Material
State your resin early. Common choices include PE, PP, PS and PET-based materials. The material affects mold design, temperature settings and the machine you need.Output and cavities
Set a realistic hourly target. More cavities raise output, but they also need a larger machine and a more precise mold.Supplier support
Ask every supplier for a written specification, sample bottles or test videos, spare parts support and clear warranty terms. A supplier who asks detailed questions about your bottle is usually a better partner than one who quotes a price straight away.What Affects the Price of an Injection Blow Molding Machine?
The price of an injection blow molding machine is not a single number. These factors move it up or down:• Model size, from ZQ40 to ZQ135
• Drive type: all-electric, servo or hydraulic
• Number of cavities and mold design
• Control system and automation options
• Auxiliary equipment
• Shipping, installation and training
Compare quotations line by line. A low price may leave out molds, spare parts or training. Ask what is included before you decide.
Why Buyers in 30+ Countries Choose Ziqiang Machinery
Buyers need more than a machine. They need a supplier who answers questions clearly, delivers as agreed and supports the equipment after delivery. Here is what Ziqiang offers:• Focus on injection blow molding for small bottles
• Three drive options: all-electric, servo and hydraulic
• Machines, molds and auxiliary equipment from one supplier
• OEM/ODM mold support
• Export experience across 30+ countries and regions
• 20+ years of industry experience
Need documents or test videos for your internal approval? Ask our team, and we will tell you what we can provide.
Frequently Asked Questions
What bottle sizes can an injection blow molding machine produce?
IBM is designed mainly for small and medium bottles. The exact volume range depends on the machine model and the mold. Send us your bottle sample or drawing, and we will confirm which ZQ model fits.Which materials can I use?
IBM machines commonly process PE, PP, PS and PET-based resins. Your final choice depends on the bottle design and the product inside. Tell us your resin, and we will confirm compatibility before we quote.Do you supply bottle molds?
Yes. We provide OEM/ODM molds and can build a turnkey project that includes the machine, mold and supporting equipment.Is IBM better than extrusion blow molding for small bottles?
For small bottles with precise necks, usually yes. IBM gives accurate neck finishes and almost no flash. EBM is often better for large bottles or designs with handles.What information do you need for a quotation?
Send your bottle sample or drawing, volume, material, target output, preferred drive type, voltage and destination port.Do you export overseas and provide support?
Yes. We sell to buyers in 30+ countries and regions and offer worldwide export support. Contact us to discuss installation guidance, training and spare parts for your project.Conclusion
The right blow molding machine for small bottles depends on your bottle, your material and your output target. Ziqiang Machinery supplies all-electric, servo and hydraulic IBM machines, OEM/ODM molds and auxiliary equipment from one factory in China.Ready to compare options? Send us your bottle sample or drawing and your target output. Our team can provide product details, a quotation, mold customization, sample options and technical support. Contact us today, or message us on WhatsApp at +86 13913614902.
